Capture Net Launcher YE-01 8-10m Range 9㎡ Net Laser Aimed Fits DJI M300/M350

MYUAV TECHNOLOGIES CO.,LTD.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Capture Net Launcher YE-01 8-10m Range 9㎡ Net Laser Aimed Fits DJI M300/M350

Brand Name : MYUAV

Model Number : YE-01

Place of Origin : China

MOQ : 1

Price : 2394 USD

Payment Terms : T/T L/C D/P D/A

Delivery Time : 2 weeks

Packaging Details : case

Product Model : YE-01

Product Dimensions : 248mm * 73mm * 121mm

Product Weight : 1280g (±20g)

System Power : ≤20W

Effective Range : 8-10m

Number of Channels : 1

Protection Class : IP45

Launch Angle : 20° Downward

Control Method : DJi Pilot2

Load Interface : SKYPORT V2.0

Compatible Models : DJI M300/M350

Recoil Force : 0.58kg

Contact Now

Introduction to the Capture Net Launcher (YE-01)

The Capture Net Launcher (Model YE-01) is a non-lethal capture device designed for drone mounting. With precise launching capabilities and reliable performance, it is ideal for rapid target control in scenarios such as security and wildlife rescue. Below is a detailed overview of its core performance, design features, and compatibility:

I. Core Parameters and Capture Capabilities

  • Material and Specifications: Constructed from a composite of aviation aluminum alloy and plastic, balancing durability and lightweight design. It measures 248mm × 73mm × 121mm and weighs 1280g (±20g), minimizing impact on the drone’s payload.
  • Capture Efficiency: Boasts an effective range of 8-10m and a net deployment area of 9㎡ (3×3m), enabling rapid target coverage. With a recoil force of only 0.58kg, it ensures stable drone posture after launch.
  • Power and Energy Consumption: Equipped with a 16g high-pressure nitrogen cylinder as the power unit, the system operates at ≤20W, ensuring low energy consumption and stable activation.

II. Design Details and Safety Features

  • Environmental Adaptability: Functions within a temperature range of -20℃ to 45℃ and holds an IP45 protection rating, resisting dust and low-pressure water jets to adapt to complex outdoor conditions.
  • Operational Convenience: Supports a 20° downward launch angle and features laser-assisted aiming for enhanced long-distance accuracy. Its quick-release mounting design allows easy installation under the drone’s belly.
  • Safety Mechanisms: Equipped with an independent unlocking switch to prevent misoperation. The single-channel design simplifies operation, ensuring precise execution of launch commands.

III. Compatibility and Control

  • System Integration: Connects via the SKYPORT V2.0 payload interface, compatible with DJI M300/M350 drones. Controlled through the DJI Pilot 2 system, its control distance matches the drone’s communication range, enabling remote and convenient operation.

Capture Net Launcher YE-01 8-10m Range 9㎡ Net Laser Aimed Fits DJI M300/M350

In summary, the YE-01 Capture Net Launcher combines precision, safety, and ease of use, making it an ideal auxiliary device for drones performing non-contact capture missions, balancing efficiency and reliability.

Support and Services:

The Tethered Drone Station product comes with comprehensive technical support and services to ensure optimal performance and reliability. Our team of experienced technicians is available to provide support via phone, email, or remote access. In addition, we offer on-site installation and training services to ensure that our customers are able to operate the product safely and efficiently.
We also provide maintenance and repair services to keep the product in top working condition. Our technicians can perform routine maintenance tasks, such as cleaning and calibration, as well as more complex repairs if necessary.
Finally, we offer customization services to tailor the product to the specific needs of our customers. This may include modifications to the hardware or software, or the integration of additional features or components.
